Basic parameters
Model name
Beijing Off-Road BJ30 2024 1.5T Magic Core Electric Drive Advanced Edition
FAW Audi
BAIC Off-Road
Compact SUV
Energy type
Gasoline
Gas-electric hybrid
National VI
Time to market
Maximum power (kW)
2024.05
Maximum power(kW)
301
Maximum torque (N┬╖m)
685
Engine
1.5T 158 horsepower L4
Motor(Ps)
252
gearbox
2nd gear DHT
Length*width*height (mm)
4730*1910*1790
body structure
5-door, 5-seater SUV
Maximum speed (km/h)
170
Official 0-100km/h acceleration (s)
-
WLTC comprehensive fuel consumption (L/100km)
6.45
Vehicle warranty
Five years or 150,000 kilometers
First owner warranty policy
-
Body
length (mm)
4730
width (mm)
1910
height (mm)
1790
wheelbase (mm)
2820
front wheelbase (mm)
1625
rear wheelbase (mm)
1635
minimum ground clearance for full load Gap (mm)
215
approach angle (┬░)
25
departure angle (┬░)
30
Longitudinal passage angle (┬░)
21
body structure
SUV
door opening method
swing door
number of doors (units)
5
Number of seats (seats)
5
Fuel tank volume (L)
51
Trunk volume (L)
-
Curb weight (kg)
1770
Maximum full load mass (kg)
2205
Engine
Engine model
A156T2H-H1
Displacement (mL)
1498
Displacement(L)
1.5
Intake form
turbocharging
Engine layout
horizontal
Cylinder arrangement
L
Number of cylinders (number)
4
Number of valves per cylinder (number)
4
Valve train
DOHC
Maximum horsepower (Ps)
158
Maximum power(kW)
116
Maximum power speed (rpm)
-
Maximum torque (N┬╖m)
235
Maximum torque speed (rpm)
-
Maximum net power (kW)
113
fuel form
Gas-electric hybrid
fuel grade
No. 92
Fuel supply method
direct injection
Cylinder head material
Aluminum alloy
Cylinder material
Aluminum alloy
National VI
Time to market
electric motor
Motor type
Permanent magnet/synchronization
Total motor power (kW)
185
Total motor power (Ps)
-
Total torque of motor (N┬╖m)
450
Maximum power of front electric motor (kW)
130
Maximum torque of front electric motor (N┬╖m)
315
Maximum power of rear electric motor (kW)
55
Maximum torque of rear electric motor (N┬╖m)
135
System comprehensive power (kW)
301
System comprehensive power (Ps)
409
System comprehensive torque (N┬╖m)
685
Number of drive motors
Dual motor
Motor layout
Front rear
Battery type
Ternary lithium battery
Battery brand
hive energy
Battery energy (kWh)
1.67
Electricity consumption per 100 kilometers (kWh/100km)
-
Battery pack warranty
Eight years or 150,000 kilometers
Fast charging function
-
Fast charging time (hours)
-
Slow charging time (hours)
-
Fast charging capacity (%)
-
gearbox
Number of gears
2
Gearbox type
Dedicated Hybrid Transmission (DHT)
abbreviation
2nd gear DHT
chassis steering
Drive mode
Front four-wheel drive
four-wheel drive
timely four-wheel drive
Center differential structure
-
Front suspension type
MacPherson independent suspension
rear suspension type
Multi-link independent suspension
Assist type
electric assist
Body structure
Load-bearing
wheel brake
Front brake type
ventilated disc
rear brake type
disc type
Parking brake type
Electronic parking
Front tire specifications
235/60 R19
Rear tire specifications
235/60 R19
Spare tire specifications
Tire repair tools
