Basic parameters
Model name
smart Elf #1 2022 Pro version
FAW Audi
smart
Compact SUV
small SUV
Gasoline
pure electric
Maximum power (kW)
2022.06
CLTC pure electric cruising range (km)
535
Fast charging time (hours)
-
Slow charging time (hours)
-
Fast charging percentage
80
Maximum power(kW)
200
Maximum torque (N·m)
343
Motor(Ps)
272
Length*width*height (mm)
4270*1822*1636
body structure
5-door, 5-seater SUV
Maximum speed (km/h)
180
Official 0-100km/h acceleration (s)
6.7
Electric energy equivalent fuel consumption (L/100km)
1.52
Vehicle warranty
Four years or 150,000 kilometers
First owner warranty policy
-
Body
length (mm)
4270
width (mm)
1822
height (mm)
1636
wheelbase (mm)
2750
front wheelbase (mm)
1581
rear wheelbase (mm)
1586
Minimum ground clearance without load (mm)
181
approach angle (°)
18.2
departure angle (°)
30.5
body structure
SUV
door opening method
swing door
number of doors (units)
5
Number of seats (seats)
5
Front trunk volume (L)
15
Trunk volume (L)
323-986
Curb weight (kg)
1770
Maximum full load mass (kg)
2160
electric motor
Motor type
Permanent magnet/synchronization
Total motor power (kW)
200
Total motor power (Ps)
272
Total torque of motor (N·m)
343
Maximum power of rear electric motor (kW)
200
Maximum torque of rear electric motor (N·m)
343
Number of drive motors
single motor
Motor layout
rear
Battery type
Ternary lithium battery
Battery brand
Vair Electric
Battery cooling method
liquid cooling
Exchange battery
Not supported
CLTC pure electric cruising range (km)
535
Battery energy (kWh)
66
Battery energy density (Wh/kg)
184.4
Electricity consumption per 100 kilometers (kWh/100km)
13.4
Battery pack warranty
Eight years or 150,000 kilometers
Fast charging function
support
Fast charging power (kW)
150
Fast charging time (hours)
-
Slow charging time (hours)
-
Fast charging capacity (%)
80
gearbox
Number of gears
1
Gearbox type
fixed ratio gearbox
abbreviation
Electric vehicle single speed gearbox
chassis steering
Drive mode
rear wheel drive
four-wheel drive
-
Center differential structure
-
Front suspension type
MacPherson independent suspension
rear suspension type
Five-link independent suspension
Assist type
electric assist
Body structure
Load-bearing
wheel brake
Front brake type
ventilated disc
rear brake type
disc type
Parking brake type
Electronic parking
Front tire specifications
235/50 R18
Rear tire specifications
235/50 R18
Spare tire specifications
Tire repair tools
