Basic parameters
Model name
AION V 2022 Plus 70 Smart Technology Edition ternary lithium
FAW Audi
AION
Compact SUV
Energy type
Gasoline
pure electric
Maximum power (kW)
2022.04
NEDC pure electric cruising range (km)
500
Fast charging time (hours)
-
Slow charging time (hours)
-
Fast charging percentage
-
Maximum power(kW)
165
Maximum torque (N·m)
350
Motor(Ps)
224
Length*width*height (mm)
4650*1920*1720
body structure
5-door, 5-seater SUV
Maximum speed (km/h)
185
Official 0-100km/h acceleration (s)
7.9
Electric energy equivalent fuel consumption (L/100km)
1.7
Vehicle warranty
Four years or 150,000 kilometers
First owner warranty policy
-
Body
length (mm)
4650
width (mm)
1920
height (mm)
1720
wheelbase (mm)
2830
front wheelbase (mm)
1630
rear wheelbase (mm)
1645
minimum ground clearance for full load Gap (mm)
160
approach angle (°)
18
departure angle (°)
22
Maximum gradient (%)
30
Maximum climbing angle (°)
16.7
minimum turning radius (m)
6
body structure
SUV
door opening method
swing door
number of doors (units)
5
Number of seats (seats)
5
Trunk volume (L)
405
Curb weight (kg)
1905
Maximum full load mass (kg)
2350
electric motor
Motor type
Permanent magnet/synchronization
Total motor power (kW)
165
Total motor power (Ps)
-
Total torque of motor (N·m)
350
Maximum power of front electric motor (kW)
165
Maximum torque of front electric motor (N·m)
350
Number of drive motors
single motor
Motor layout
prefix
Battery type
Ternary lithium battery
Battery brand
Funeng Technology
Battery cooling method
liquid cooling
NEDC pure electric cruising range (km)
500
Battery energy (kWh)
69.9
Battery energy density (Wh/kg)
166
Electricity consumption per 100 kilometers (kWh/100km)
14.9
Battery pack warranty
There is no limit on the number of years/mileage for the first owner of the car (the liability exemption clause shall be subject to the official)
Fast charging function
support
Fast charging time (hours)
-
Slow charging time (hours)
-
Fast charging capacity (%)
-
gearbox
Number of gears
1
Gearbox type
fixed ratio gearbox
abbreviation
Electric vehicle single speed gearbox
chassis steering
Drive mode
Front wheel drive
four-wheel drive
-
Center differential structure
-
Front suspension type
MacPherson independent suspension
rear suspension type
Multi-link independent suspension
Assist type
electric assist
Body structure
Load-bearing
wheel brake
Front brake type
ventilated disc
rear brake type
disc type
Parking brake type
Electronic parking
Front tire specifications
235/55 R19
Rear tire specifications
235/55 R19
Spare tire specifications
None
