Basic parameters
Model name
AION Y 2023 Plus 610 Enjoy Edition
FAW Audi
AION
Compact SUV
Energy type
Gasoline
pure electric
Maximum power (kW)
2024.01
CLTC pure electric cruising range (km)
610
Fast charging time (hours)
-
Slow charging time (hours)
-
Fast charging percentage
-
Maximum power(kW)
150
Maximum torque (N·m)
225
Motor(Ps)
204
Length*width*height (mm)
4535*1870*1650
body structure
5-door, 5-seater SUV
Maximum speed (km/h)
150
Official 0-100km/h acceleration (s)
-
Electric energy equivalent fuel consumption (L/100km)
1.43
Vehicle warranty
Four years or 150,000 kilometers
First owner warranty policy
-
Body
length (mm)
4535
width (mm)
1870
height (mm)
1650
wheelbase (mm)
2750
front wheelbase (mm)
1600
rear wheelbase (mm)
1600
minimum ground clearance for full load Gap (mm)
150
approach angle (°)
18
departure angle (°)
27
Maximum gradient (%)
30
Maximum climbing angle (°)
16.7
minimum turning radius (m)
5.5
body structure
SUV
door opening method
swing door
number of doors (units)
5
Number of seats (seats)
5
Trunk volume (L)
405
Curb weight (kg)
1650
Maximum full load mass (kg)
2180
electric motor
Motor type
Permanent magnet/synchronization
Total motor power (kW)
150
Total motor power (Ps)
-
Total torque of motor (N·m)
225
Maximum power of front electric motor (kW)
150
Maximum torque of front electric motor (N·m)
225
Number of drive motors
single motor
Motor layout
prefix
Battery type
Lithium iron phosphate battery
Battery cooling method
liquid cooling
Exchange battery
Not supported
CLTC pure electric cruising range (km)
610
Battery energy (kWh)
68.2
Electricity consumption per 100 kilometers (kWh/100km)
12.6
Battery pack warranty
Lifetime warranty on the electric drive system for non-commercial vehicles (original owner, up to 30,000 km per year)
Fast charging function
support
Fast charging time (hours)
-
Slow charging time (hours)
-
Fast charging capacity (%)
-
gearbox
Number of gears
1
Gearbox type
fixed ratio gearbox
abbreviation
Electric vehicle single speed gearbox
chassis steering
Drive mode
Front wheel drive
four-wheel drive
-
Center differential structure
-
Front suspension type
MacPherson independent suspension
rear suspension type
torsion beam non-independent suspension
Assist type
electric assist
Body structure
Load-bearing
wheel brake
Front brake type
ventilated disc
rear brake type
disc type
Parking brake type
Electronic parking
Front tire specifications
215/55 R17
Rear tire specifications
215/55 R17
Spare tire specifications
-
