Basic parameters
Model name
Explorer 2024 2.3T EcoBoost Kunlun Peak Edition 7 seats
FAW Audi
Changan Ford
Compact SUV
Medium and large SUV
Gasoline
Environmental standards
National VI
Time to market
Maximum power (kW)
2024.09
Maximum power(kW)
213
Maximum torque (N·m)
445
Engine
2.3T 289 horsepower L4
gearbox
10-speed automatic manual transmission
Length*width*height (mm)
5066*2004*1797
body structure
5-door, 7-seater SUV
Maximum speed (km/h)
180
Official 0-100km/h acceleration (s)
-
WLTC comprehensive fuel consumption (L/100km)
10.6
Vehicle warranty
Three years or 100,000 kilometers
First owner warranty policy
-
Body
length (mm)
5066
width (mm)
2004
height (mm)
1797
wheelbase (mm)
3025
front wheelbase (mm)
1700
rear wheelbase (mm)
1700
minimum ground clearance for full load Gap (mm)
219
approach angle (°)
23
departure angle (°)
24
minimum turning radius (m)
5.9
body structure
SUV
door opening method
swing door
number of doors (units)
5
Number of seats (seats)
7
Fuel tank volume (L)
81
Trunk volume (L)
515-2487
Curb weight (kg)
2146
Total mass of quasi-trailer (kg)
2100
Maximum full load mass (kg)
2755
Engine
Engine model
CAF484WQMA
Displacement (mL)
2261
Displacement(L)
2.3
Intake form
turbocharging
Engine layout
vertically placed
Cylinder arrangement
L
Number of cylinders (number)
4
Number of valves per cylinder (number)
4
Compression ratio
10.6
Valve train
DOHC
Maximum horsepower (Ps)
289
Maximum power(kW)
213
Maximum power speed (rpm)
5500
Maximum torque (N·m)
445
Maximum torque speed (rpm)
2500-4500
Maximum net power (kW)
211
fuel form
Environmental standards
fuel grade
No. 92
Fuel supply method
direct injection
Cylinder head material
Aluminum alloy
Cylinder material
Aluminum alloy
National VI
Time to market
gearbox
Number of gears
10
Gearbox type
Automatic manual transmission (AT)
abbreviation
10-speed automatic manual transmission
chassis steering
Drive mode
Front four-wheel drive
four-wheel drive
timely four-wheel drive
Center differential structure
multi-disc clutch
Front suspension type
MacPherson independent suspension
rear suspension type
Multi-link independent suspension
Assist type
electric assist
Body structure
Load-bearing
wheel brake
Front brake type
ventilated disc
rear brake type
disc type
Parking brake type
Electronic parking
Front tire specifications
265/65 R18
Rear tire specifications
265/65 R18
Spare tire specifications
Not full size
