Basic parameters
Model name
Trumpchi E9 2025 E9 Super Fast Charging Exclusive
FAW Audi
GAC Trumpchi
Compact SUV
Medium and large MPV
Gasoline
plug-in hybrid
National VI
Time to market
Maximum power (kW)
2024.11
WLTC pure electric cruising range (km)
106
CLTC pure electric cruising range (km)
136
Fast charging time (hours)
0.13
Slow charging time (hours)
3.5
Fast charging percentage
30-80
Maximum power(kW)
274
Maximum torque (N·m)
630
Engine
2.0T190 horsepowerL4
Motor(Ps)
182
gearbox
2nd gear DHT
Length*width*height (mm)
5212*1893*1823
body structure
5-door, 7-seater MPV
Maximum speed (km/h)
175
Official 0-100km/h acceleration (s)
8.8
WLTC comprehensive fuel consumption (L/100km)
1.3
Vehicle warranty
Three years or 100,000 kilometers
First owner warranty policy
-
Body
length (mm)
5212
width (mm)
1893
height (mm)
1823
wheelbase (mm)
3070
front wheelbase (mm)
1625
rear wheelbase (mm)
1646
approach angle (°)
12
departure angle (°)
16
body structure
MPV
door opening method
Swing door sliding door
number of doors (units)
5
Number of seats (seats)
7
Fuel tank volume (L)
56
Trunk volume (L)
-
Curb weight (kg)
2420
Maximum full load mass (kg)
3000
Engine
Engine model
4B20J2
Displacement (mL)
1991
Displacement(L)
2.0
Intake form
turbocharging
Engine layout
horizontal
Cylinder arrangement
L
Number of cylinders (number)
4
Number of valves per cylinder (number)
4
Valve train
DOHC
Maximum horsepower (Ps)
190
Maximum power(kW)
140
Maximum power speed (rpm)
-
Maximum torque (N·m)
330
Maximum torque speed (rpm)
-
Maximum net power (kW)
140
fuel form
plug-in hybrid
fuel grade
No. 92
Fuel supply method
direct injection
Cylinder head material
Aluminum alloy
Cylinder material
Aluminum alloy
National VI
Time to market
electric motor
Motor type
Permanent magnet/synchronization
Total motor power (kW)
134
Total motor power (Ps)
-
Total torque of motor (N·m)
300
Maximum power of front electric motor (kW)
134
Maximum torque of front electric motor (N·m)
300
System comprehensive power (kW)
274
System comprehensive power (Ps)
373
System comprehensive torque (N·m)
630
Number of drive motors
single motor
Motor layout
prefix
Battery type
Ternary lithium battery
Battery brand
Guangzhou Juwan
Battery cooling method
liquid cooling
WLTC pure electric cruising range (km)
106
CLTC pure electric cruising range (km)
136
WLTC comprehensive range (km)
983
Battery energy (kWh)
25.5
Electricity consumption per 100 kilometers (kWh/100km)
21.5
Battery pack warranty
Eight years or 150,000 kilometers
Fast charging function
support
Fast charging time (hours)
0.13
Slow charging time (hours)
3.5
Fast charging capacity (%)
30-80
gearbox
Number of gears
2
Gearbox type
Dedicated Hybrid Transmission (DHT)
abbreviation
2nd gear DHT
chassis steering
Drive mode
Front wheel drive
four-wheel drive
-
Center differential structure
-
Front suspension type
MacPherson independent suspension
rear suspension type
Multi-link independent suspension
Assist type
electric assist
Body structure
Load-bearing
wheel brake
Front brake type
ventilated disc
rear brake type
ventilated disc
Parking brake type
Electronic parking
Front tire specifications
225/60 R18
Rear tire specifications
225/60 R18
Spare tire specifications
-
