Basic parameters
Model name
Xpeng G9 2024 570 Pro
FAW Audi
Xpeng Motors
Compact SUV
Medium and large SUV
Gasoline
pure electric
Maximum power (kW)
2023.09
CLTC pure electric cruising range (km)
570
Fast charging time (hours)
0.33
Slow charging time (hours)
-
Fast charging percentage
10-80
Maximum power(kW)
230
Maximum torque (N·m)
430
Motor(Ps)
313
Length*width*height (mm)
4891*1937*1680
body structure
5-door, 5-seater SUV
Maximum speed (km/h)
200
Official 0-100km/h acceleration (s)
6.4
Electric energy equivalent fuel consumption (L/100km)
1.72
Vehicle warranty
Five years or 120,000 kilometers
First owner warranty policy
-
Body
length (mm)
4891
width (mm)
1937
height (mm)
1680
wheelbase (mm)
2998
front wheelbase (mm)
1656
rear wheelbase (mm)
1663
minimum ground clearance for full load Gap (mm)
145
approach angle (°)
19
departure angle (°)
20
minimum turning radius (m)
5.9
body structure
SUV
door opening method
swing door
number of doors (units)
5
Number of seats (seats)
5
Front trunk volume (L)
71
Trunk volume (L)
660-1576
Drag coefficient (Cd)
0.272
Curb weight (kg)
2230
Maximum full load mass (kg)
2680
electric motor
Motor type
Permanent magnet/synchronization
Total motor power (kW)
230
Total motor power (Ps)
-
Total torque of motor (N·m)
430
Maximum power of rear electric motor (kW)
230
Maximum torque of rear electric motor (N·m)
430
Number of drive motors
single motor
Motor layout
rear
Battery type
Lithium iron phosphate battery
Battery brand
Made by Zhipeng
Battery cooling method
liquid cooling
Exchange battery
Not supported
CLTC pure electric cruising range (km)
570
Battery energy (kWh)
78.2
Battery energy density (Wh/kg)
130
Electricity consumption per 100 kilometers (kWh/100km)
15.2
Battery pack warranty
Eight years or 160,000 kilometers
Fast charging function
support
Fast charging power (kW)
315
High voltage fast charging
support
Fast charging time (hours)
0.33
Slow charging time (hours)
-
Fast charging capacity (%)
10-80
gearbox
Number of gears
1
Gearbox type
fixed ratio gearbox
abbreviation
Electric vehicle single speed gearbox
chassis steering
Drive mode
rear wheel drive
four-wheel drive
-
Center differential structure
-
Front suspension type
Double wishbone independent suspension
rear suspension type
Multi-link independent suspension
Assist type
electric assist
Body structure
Load-bearing
wheel brake
Front brake type
ventilated disc
rear brake type
ventilated disc
Parking brake type
Electronic parking
Front tire specifications
255/55 R19
Rear tire specifications
255/55 R19
Spare tire specifications
Tire repair tools
