Basic parameters
Model name
Dark blue G318 2024 four-wheel drive air suspension version
FAW Audi
dark blue car
Compact SUV
Medium and large SUV
Gasoline
Extended range
National VI
Time to market
Maximum power (kW)
2024.06
WLTC pure electric cruising range (km)
138
CLTC pure electric cruising range (km)
174
Fast charging time (hours)
0.5
Slow charging time (hours)
5
Fast charging percentage
30-80
Maximum power(kW)
316
Maximum torque (N·m)
572
Engine
Range extender 150 HP
Motor(Ps)
430
gearbox
Electric vehicle single speed gearbox
Length*width*height (mm)
5010*1985*1960
body structure
5-door, 5-seater SUV
Maximum speed (km/h)
185
Official 0-100km/h acceleration (s)
6.3
WLTC comprehensive fuel consumption (L/100km)
1.69
Electric energy equivalent fuel consumption (L/100km)
2.58
Vehicle warranty
Three years or 120,000 kilometers
First owner warranty policy
No limit on years/unlimited mileage (the liability exemption clause shall be subject to the official)
Body
length (mm)
5010
width (mm)
1985
height (mm)
1960
wheelbase (mm)
2880
front wheelbase (mm)
1690
rear wheelbase (mm)
1686
approach angle (°)
27
departure angle (°)
31
Longitudinal passage angle (°)
25
Maximum gradient (%)
60
Maximum wading depth (mm)
620
body structure
SUV
door opening method
swing door
number of doors (units)
5
Number of seats (seats)
5
Fuel tank volume (L)
60
Trunk volume (L)
818-1747
Drag coefficient (Cd)
0.4
Curb weight (kg)
2360
Total mass of quasi-trailer (kg)
1600
Maximum full load mass (kg)
2800
Engine
Engine model
JL469ZQ1
Displacement (mL)
1497
Displacement(L)
1.5
Intake form
turbocharging
Engine layout
horizontal
Cylinder arrangement
L
Number of cylinders (number)
4
Number of valves per cylinder (number)
4
Valve train
DOHC
Maximum horsepower (Ps)
150
Maximum power(kW)
110
Maximum power speed (rpm)
5000
Maximum torque (N·m)
220
Maximum torque speed (rpm)
3200-4200
Maximum net power (kW)
105
fuel form
Extended range
fuel grade
No. 92
Fuel supply method
direct injection
Cylinder head material
Aluminum alloy
Cylinder material
Aluminum alloy
National VI
Time to market
electric motor
Motor type
Front AC/asynchronous rear permanent magnet/synchronous
Total motor power (kW)
316
Total motor power (Ps)
-
Total torque of motor (N·m)
572
Maximum power of front electric motor (kW)
131
Maximum torque of front electric motor (N·m)
262
Maximum power of rear electric motor (kW)
185
Maximum torque of rear electric motor (N·m)
310
System comprehensive power (kW)
316
System comprehensive power (Ps)
430
System comprehensive torque (N·m)
572
Number of drive motors
Dual motor
Motor layout
Front rear
Battery type
Lithium iron phosphate battery
Battery brand
China New Airlines
Battery cooling method
liquid cooling
WLTC pure electric cruising range (km)
138
CLTC pure electric cruising range (km)
174
Battery energy (kWh)
35.07
Battery energy density (Wh/kg)
120
Electricity consumption per 100 kilometers (kWh/100km)
22.8
Battery pack warranty
-
Fast charging function
support
Fast charging time (hours)
0.5
Slow charging time (hours)
5
Fast charging capacity (%)
30-80
gearbox
Number of gears
1
Gearbox type
fixed ratio gearbox
abbreviation
Electric vehicle single speed gearbox
chassis steering
Drive mode
Dual motor four-wheel drive
four-wheel drive
Electric four-wheel drive
Center differential structure
-
Front suspension type
Double wishbone independent suspension
rear suspension type
Five-link independent suspension
Assist type
electric assist
Body structure
Load-bearing
wheel brake
Front brake type
ventilated disc
rear brake type
ventilated disc
Parking brake type
Electronic parking
Front tire specifications
255/55 R20
Rear tire specifications
255/55 R20
Spare tire specifications
full size
