Basic parameters
Model name
NIO EC6 2022 100kWh performance version
FAW Audi
NIO
Compact SUV
Medium SUV
Gasoline
pure electric
Maximum power (kW)
2022.06
NEDC pure electric cruising range (km)
615
Fast charging time (hours)
0.8
Slow charging time (hours)
14
Fast charging percentage
80
Maximum power(kW)
400
Maximum torque (N·m)
725
Motor(Ps)
544
Length*width*height (mm)
4850*1965*1714
body structure
5-door, 5-seat SUV crossover
Maximum speed (km/h)
200
Official 0-100km/h acceleration (s)
4.5
Electric energy equivalent fuel consumption (L/100km)
2
Vehicle warranty
Three years or 120,000 kilometers
First owner warranty policy
-
Body
length (mm)
4850
width (mm)
1965
height (mm)
1714
wheelbase (mm)
2900
front wheelbase (mm)
1668
rear wheelbase (mm)
1672
approach angle (°)
17
departure angle (°)
21
body structure
SUV crossover
door opening method
swing door
number of doors (units)
5
Number of seats (seats)
5
Trunk volume (L)
510-1405
Drag coefficient (Cd)
0.26
Curb weight (kg)
2329
Maximum full load mass (kg)
2799
electric motor
Motor type
Front Permanent Magnet/Synchronous, Rear AC/Asynchronous
Total motor power (kW)
400
Total motor power (Ps)
-
Total torque of motor (N·m)
725
Maximum power of front electric motor (kW)
160
Maximum power of rear electric motor (kW)
240
Number of drive motors
Dual motor
Motor layout
Front rear
Battery type
Ternary lithium battery
Battery brand
Suzhou Zhengli
Battery cooling method
liquid cooling
Exchange battery
support
NEDC pure electric cruising range (km)
615
Battery energy (kWh)
100
Battery energy density (Wh/kg)
185.44
Electricity consumption per 100 kilometers (kWh/100km)
17.3
Battery pack warranty
There is no limit on the number of years/mileage for the first owner of the car (the liability exemption clause shall be subject to the official)
Fast charging function
support
Fast charging time (hours)
0.8
Slow charging time (hours)
14
Fast charging capacity (%)
80
gearbox
Number of gears
1
Gearbox type
fixed ratio gearbox
abbreviation
Electric vehicle single speed gearbox
chassis steering
Drive mode
Dual motor four-wheel drive
four-wheel drive
Electric four-wheel drive
Center differential structure
-
Front suspension type
Double wishbone independent suspension
rear suspension type
Multi-link independent suspension
Assist type
electric assist
Body structure
Load-bearing
wheel brake
Front brake type
ventilated disc
rear brake type
ventilated disc
Parking brake type
Electronic parking
Front tire specifications
255/55 R19
Rear tire specifications
255/55 R19
Spare tire specifications
Tire repair tools
