Basic parameters
Model name
Corolla Plug-in Hybrid 2019 1.8L E-CVT Leading Edition
FAW Audi
FAW Toyota
Compact SUV
compact car
Gasoline
plug-in hybrid
National VI
Time to market
Maximum power (kW)
2019.03
NEDC pure electric cruising range (km)
55
Fast charging time (hours)
-
Slow charging time (hours)
-
Fast charging percentage
-
Maximum power(kW)
100
Maximum torque (N·m)
-
Engine
1.8L 99 HP L4
Motor(Ps)
72
gearbox
E-CVT continuously variable transmission
Length*width*height (mm)
4635*1775*1470
body structure
4-door, 5-seat sedan
Maximum speed (km/h)
159
Official 0-100km/h acceleration (s)
-
NEDC comprehensive fuel consumption (L/100km)
1.3
Minimum state of charge fuel consumption (L/100km)
4.3
Vehicle warranty
Three years or 100,000 kilometers
First owner warranty policy
-
Body
length (mm)
4635
width (mm)
1775
height (mm)
1470
wheelbase (mm)
2700
front wheelbase (mm)
1525
rear wheelbase (mm)
1520
approach angle (°)
14
departure angle (°)
13
body structure
sedan
door opening method
swing door
number of doors (units)
4
Number of seats (seats)
5
Fuel tank volume (L)
-
Trunk volume (L)
-
Curb weight (kg)
1535
Maximum full load mass (kg)
1975
Engine
Engine model
8ZR-FXE
Displacement (mL)
1798
Displacement(L)
1.8
Intake form
naturally aspirated
Engine layout
horizontal
Cylinder arrangement
L
Number of cylinders (number)
4
Number of valves per cylinder (number)
4
Valve train
DOHC
Maximum horsepower (Ps)
99
Maximum power(kW)
73
Maximum power speed (rpm)
-
Maximum torque (N·m)
142
Maximum torque speed (rpm)
-
Maximum net power (kW)
73
fuel form
plug-in hybrid
fuel grade
No. 92
Fuel supply method
Multi-point EFI
Cylinder head material
Aluminum alloy
Cylinder material
Aluminum alloy
National VI
Time to market
electric motor
Motor type
Permanent magnet/synchronization
Total motor power (kW)
53
Total motor power (Ps)
-
Total torque of motor (N·m)
207
Maximum power of front electric motor (kW)
53
Maximum torque of front electric motor (N·m)
207
System comprehensive power (kW)
100
Number of drive motors
single motor
Motor layout
prefix
Battery type
Lithium-ion battery
NEDC pure electric cruising range (km)
55
Battery energy (kWh)
10.5
Electricity consumption per 100 kilometers (kWh/100km)
10
Battery pack warranty
Eight years or 200,000 kilometers
Fast charging function
-
Fast charging time (hours)
-
Slow charging time (hours)
-
Fast charging capacity (%)
-
gearbox
Number of gears
Continuously variable speed
Gearbox type
Electronic continuously variable transmission (E-CVT)
abbreviation
E-CVT continuously variable transmission
chassis steering
Drive mode
Front wheel drive
four-wheel drive
-
Center differential structure
-
Front suspension type
MacPherson independent suspension
rear suspension type
torsion beam non-independent suspension
Assist type
electric assist
Body structure
Load-bearing
wheel brake
Front brake type
ventilated disc
rear brake type
disc type
Parking brake type
handbrake
Front tire specifications
205/55 R16
Rear tire specifications
205/55 R16
Spare tire specifications
Not full size
