Basic parameters
Model name
NIO ES7 2024 model 100kWh
FAW Audi
NIO
Compact SUV
Medium and large SUV
Gasoline
pure electric
Maximum power (kW)
2024.02
CLTC pure electric cruising range (km)
620
Fast charging time (hours)
0.6
Slow charging time (hours)
14
Fast charging percentage
80
Maximum power(kW)
-
Maximum torque (N·m)
-
Motor(Ps)
653
Length*width*height (mm)
4912*1987*1720
body structure
5-door, 5-seater SUV
Maximum speed (km/h)
200
Official 0-100km/h acceleration (s)
3.9
Electric energy equivalent fuel consumption (L/100km)
1.99
Vehicle warranty
Three years or 120,000 kilometers
First owner warranty policy
Six years or 150,000 kilometers
Body
length (mm)
4912
width (mm)
1987
height (mm)
1720
wheelbase (mm)
2960
front wheelbase (mm)
1668
rear wheelbase (mm)
1672
approach angle (°)
17
departure angle (°)
22
body structure
SUV
door opening method
swing door
number of doors (units)
5
Number of seats (seats)
5
Trunk volume (L)
570-1545
Drag coefficient (Cd)
0.263
Curb weight (kg)
2381
Total mass of quasi-trailer (kg)
2000
Maximum full load mass (kg)
2850
electric motor
Motor type
Front Permanent Magnet/Synchronous, Rear AC/Asynchronous
Total motor power (kW)
480
Total motor power (Ps)
-
Total torque of motor (N·m)
850
Maximum power of front electric motor (kW)
180
Maximum torque of front electric motor (N·m)
350
Maximum power of rear electric motor (kW)
300
Maximum torque of rear electric motor (N·m)
500
Number of drive motors
Dual motor
Motor layout
Front rear
Battery type
Ternary lithium battery
Battery brand
Ningde Era (Jiangsu Era)
Battery cooling method
liquid cooling
Exchange battery
support
CLTC pure electric cruising range (km)
620
Battery energy (kWh)
100
Battery energy density (Wh/kg)
185.44
Electricity consumption per 100 kilometers (kWh/100km)
17.6
Battery pack warranty
Ten years of unlimited mileage for the first owner (the liability exemption clause shall be subject to the official)
Fast charging function
support
Fast charging power (kW)
180
Fast charging time (hours)
0.6
Slow charging time (hours)
14
Fast charging capacity (%)
80
gearbox
Number of gears
1
Gearbox type
fixed ratio gearbox
abbreviation
Electric vehicle single speed gearbox
chassis steering
Drive mode
Dual motor four-wheel drive
four-wheel drive
Electric four-wheel drive
Center differential structure
-
Front suspension type
Double wishbone independent suspension
rear suspension type
Multi-link independent suspension
Assist type
electric assist
Body structure
Load-bearing
wheel brake
Front brake type
ventilated disc
rear brake type
ventilated disc
Parking brake type
Electronic parking
Front tire specifications
255/50 R20
Rear tire specifications
255/50 R20
Spare tire specifications
Tire repair tools
