Basic parameters
Model name
Hongqi E-HS9 2022 model 660km flag collar version four seats
FAW Audi
FAW Hongqi
Compact SUV
Large SUV
Gasoline
pure electric
Maximum power (kW)
2021.11
NEDC pure electric cruising range (km)
660
Fast charging time (hours)
-
Slow charging time (hours)
-
Fast charging percentage
-
Maximum power(kW)
405
Maximum torque (N·m)
750
Motor(Ps)
551
Length*width*height (mm)
5209*2010*1713
body structure
5-door, 4-seater SUV
Maximum speed (km/h)
200
Official 0-100km/h acceleration (s)
-
Electric energy equivalent fuel consumption (L/100km)
2.1
Vehicle warranty
Four years or 100,000 kilometers
First owner warranty policy
No limit on years/unlimited mileage (the liability exemption clause shall be subject to the official)
Body
length (mm)
5209
width (mm)
2010
height (mm)
1713
wheelbase (mm)
3110
front wheelbase (mm)
1708
rear wheelbase (mm)
1709
minimum ground clearance for full load Gap (mm)
175
approach angle (°)
21
departure angle (°)
21
body structure
SUV
door opening method
swing door
number of doors (units)
5
Number of seats (seats)
4
Trunk volume (L)
-
Curb weight (kg)
2712
Maximum full load mass (kg)
3162
electric motor
Motor type
Permanent magnet/synchronization
Total motor power (kW)
405
Total motor power (Ps)
-
Total torque of motor (N·m)
750
Maximum power of front electric motor (kW)
160
Maximum torque of front electric motor (N·m)
300
Maximum power of rear electric motor (kW)
245
Maximum torque of rear electric motor (N·m)
450
Number of drive motors
Dual motor
Motor layout
Front rear
Battery type
Ternary lithium battery
Battery brand
Ningde era
Battery cooling method
liquid cooling
NEDC pure electric cruising range (km)
660
Battery energy (kWh)
120
Battery energy density (Wh/kg)
206
Electricity consumption per 100 kilometers (kWh/100km)
19
Battery pack warranty
Eight years or 160,000 kilometers
Fast charging function
support
Fast charging time (hours)
-
Slow charging time (hours)
-
Fast charging capacity (%)
-
gearbox
Number of gears
1
Gearbox type
fixed ratio gearbox
abbreviation
Electric vehicle single speed gearbox
chassis steering
Drive mode
Dual motor four-wheel drive
four-wheel drive
Electric four-wheel drive
Center differential structure
-
Front suspension type
Double wishbone independent suspension
rear suspension type
Multi-link independent suspension
Assist type
electric assist
Body structure
Load-bearing
wheel brake
Front brake type
ventilated disc
rear brake type
ventilated disc
Parking brake type
Electronic parking
Front tire specifications
275/40 R22
Rear tire specifications
275/40 R22
Spare tire specifications
None
