Basic parameters
Model name
Beijing BJ40 2021 2.3T automatic four-wheel drive Blade Hero Edition Supreme
FAW Audi
BAIC Off-Road
Compact SUV
Energy type
Gasoline
Environmental standards
National VI
Time to market
Maximum power (kW)
2021.03
Maximum power(kW)
170
Maximum torque (N·m)
345
Engine
2.3T 231 horsepower L4
gearbox
6-speed manual transmission
Length*width*height (mm)
4645*1925*1871
body structure
4-door 5-seater SUV
Maximum speed (km/h)
160
Official 0-100km/h acceleration (s)
-
NEDC comprehensive fuel consumption (L/100km)
10.6
Vehicle warranty
Three years or 100,000 kilometers
First owner warranty policy
-
Body
length (mm)
4645
width (mm)
1925
height (mm)
1871
wheelbase (mm)
2745
front wheelbase (mm)
1610
rear wheelbase (mm)
1610
Minimum ground clearance without load (mm)
220
approach angle (°)
37
departure angle (°)
31
Longitudinal passage angle (°)
23
Maximum gradient (%)
60
Maximum climbing angle (°)
31
Maximum wading depth (mm)
750
body structure
SUV
door opening method
swing door
number of doors (units)
4
Number of seats (seats)
5
Fuel tank volume (L)
75
Trunk volume (L)
532-965
Curb weight (kg)
2115
Maximum full load mass (kg)
2540
Engine
Engine model
B237R
Displacement (mL)
2290
Displacement(L)
2.3
Intake form
turbocharging
Engine layout
vertically placed
Cylinder arrangement
L
Number of cylinders (number)
4
Number of valves per cylinder (number)
4
Valve train
DOHC
Maximum horsepower (Ps)
231
Maximum power(kW)
170
Maximum power speed (rpm)
5200
Maximum torque (N·m)
345
Maximum torque speed (rpm)
1900-4000
Maximum net power (kW)
160
fuel form
Environmental standards
fuel grade
No. 95
Fuel supply method
Multi-point EFI
Cylinder head material
Aluminum alloy
Cylinder material
cast iron
National VI
Time to market
gearbox
Number of gears
6
Gearbox type
Automatic manual transmission (AT)
abbreviation
6-speed manual transmission
chassis steering
Drive mode
Front four-wheel drive
four-wheel drive
four-link non-independent suspension
Center differential structure
-
Front suspension type
Double wishbone independent suspension
rear suspension type
5-link non-independent suspension
Assist type
Mechanical hydraulic assist
Body structure
Non-load-bearing
wheel brake
Front brake type
ventilated disc
rear brake type
disc type
Parking brake type
Electronic parking
Front tire specifications
265/65 R17
Rear tire specifications
265/65 R17
Spare tire specifications
full size
