Basic parameters
Model name
Dark blue S09 2025 four-wheel drive Ultra high-end version
FAW Audi
dark blue car
Compact SUV
Large SUV
Gasoline
Extended range
National VI
Time to market
Maximum power (kW)
2025.04
WLTC pure electric cruising range (km)
170
CLTC pure electric cruising range (km)
210
Fast charging time (hours)
0.25
Slow charging time (hours)
6
Fast charging percentage
30-80
Maximum power(kW)
362
Maximum torque (N·m)
637
Engine
Range extender 150 HP
Motor(Ps)
493
gearbox
Electric vehicle single speed gearbox
Length*width*height (mm)
5205*1996*1800
body structure
5-door, 6-seater SUV
Maximum speed (km/h)
205
Official 0-100km/h acceleration (s)
5.9
WLTC comprehensive fuel consumption (L/100km)
0.91
Electric energy equivalent fuel consumption (L/100km)
2.71
Vehicle warranty
Five years or 100,000 kilometers
First owner warranty policy
-
Body
length (mm)
5205
width (mm)
1996
height (mm)
1800
wheelbase (mm)
3105
front wheelbase (mm)
1690
rear wheelbase (mm)
1700
approach angle (°)
19
departure angle (°)
21
minimum turning radius (m)
5.8
body structure
SUV
door opening method
swing door
number of doors (units)
5
Number of seats (seats)
6
Fuel tank volume (L)
50
Trunk volume (L)
427-1392
Drag coefficient (Cd)
0.283
Curb weight (kg)
2668
Maximum full load mass (kg)
3180
Engine
Engine model
JL469ZQ1
Displacement (mL)
1497
Displacement(L)
1.5
Intake form
turbocharging
Engine layout
horizontal
Cylinder arrangement
L
Number of cylinders (number)
4
Number of valves per cylinder (number)
4
Valve train
DOHC
Maximum horsepower (Ps)
150
Maximum power(kW)
110
Maximum power speed (rpm)
5000
Maximum torque (N·m)
220
Maximum torque speed (rpm)
3200-4200
Maximum net power (kW)
105
fuel form
Extended range
fuel grade
No. 92
Fuel supply method
direct injection
Cylinder head material
Aluminum alloy
Cylinder material
Aluminum alloy
National VI
Time to market
electric motor
Motor type
Front AC/asynchronous rear permanent magnet/synchronous
Total motor power (kW)
362
Total motor power (Ps)
-
Total torque of motor (N·m)
637
Maximum power of front electric motor (kW)
131
Maximum torque of front electric motor (N·m)
262
Maximum power of rear electric motor (kW)
231
Maximum torque of rear electric motor (N·m)
375
Number of drive motors
Dual motor
Motor layout
Front rear
Battery type
Lithium iron phosphate battery
Battery brand
Ningde Era (Sichuan Era)
Battery cooling method
liquid cooling
WLTC pure electric cruising range (km)
170
CLTC pure electric cruising range (km)
210
Battery energy (kWh)
40.18
Battery energy density (Wh/kg)
125
Electricity consumption per 100 kilometers (kWh/100km)
23.3
Battery pack warranty
-
Fast charging function
support
Fast charging time (hours)
0.25
Slow charging time (hours)
6
Fast charging capacity (%)
30-80
gearbox
Number of gears
1
Gearbox type
fixed ratio gearbox
abbreviation
Electric vehicle single speed gearbox
chassis steering
Drive mode
Dual motor four-wheel drive
four-wheel drive
Electric four-wheel drive
Center differential structure
-
Front suspension type
Double wishbone independent suspension
rear suspension type
Multi-link independent suspension
Assist type
electric assist
Body structure
Load-bearing
wheel brake
Front brake type
ventilated disc
rear brake type
ventilated disc
Parking brake type
Electronic parking
Front tire specifications
265/45 R21
Rear tire specifications
265/45 R21
Spare tire specifications
-
