Basic parameters
Model name
Denza D9 2024 Pioneer Four-Seat Founder Edition
FAW Audi
Denza Motors
Compact SUV
Medium and large MPV
Gasoline
plug-in hybrid
National VI
Time to market
Maximum power (kW)
2024.03
WLTC pure electric cruising range (km)
140
CLTC pure electric cruising range (km)
185
Fast charging time (hours)
-
Slow charging time (hours)
-
Fast charging percentage
-
Maximum power(kW)
299
Maximum torque (N·m)
681
Engine
1.5T 139 horsepower L4
Motor(Ps)
292
gearbox
E-CVT continuously variable transmission
Length*width*height (mm)
5250*1960*1900
body structure
5-door, 4-seater MPV
Maximum speed (km/h)
180
Official 0-100km/h acceleration (s)
7.9
WLTC comprehensive fuel consumption (L/100km)
1.08
Minimum state of charge fuel consumption (L/100km)
6.8
Electric energy equivalent fuel consumption (L/100km)
2.64
Vehicle warranty
Six years or 150,000 kilometers
First owner warranty policy
-
Body
length (mm)
5250
width (mm)
1960
height (mm)
1900
wheelbase (mm)
3110
front wheelbase (mm)
1675
rear wheelbase (mm)
1675
approach angle (°)
14
departure angle (°)
14
minimum turning radius (m)
5.95
body structure
MPV
door opening method
Swing door sliding door
number of doors (units)
5
Number of seats (seats)
4
Fuel tank volume (L)
53
Trunk volume (L)
650
Curb weight (kg)
2750
Maximum full load mass (kg)
3190
Engine
Engine model
BYD476ZQC
Displacement (mL)
1497
Displacement(L)
1.5
Intake form
turbocharging
Engine layout
horizontal
Cylinder arrangement
L
Number of cylinders (number)
4
Number of valves per cylinder (number)
4
Valve train
DOHC
Maximum horsepower (Ps)
139
Maximum power(kW)
102
Maximum power speed (rpm)
-
Maximum torque (N·m)
231
Maximum torque speed (rpm)
-
Maximum net power (kW)
96
Engine specific technology
VVT
fuel form
plug-in hybrid
fuel grade
No. 92
Fuel supply method
direct injection
Cylinder head material
Aluminum alloy
Cylinder material
Aluminum alloy
National VI
Time to market
electric motor
Motor type
Permanent magnet/synchronization
Total motor power (kW)
215
Total motor power (Ps)
-
Total torque of motor (N·m)
450
Maximum power of front electric motor (kW)
170
Maximum torque of front electric motor (N·m)
340
Maximum power of rear electric motor (kW)
45
Maximum torque of rear electric motor (N·m)
110
System comprehensive power (kW)
299
System comprehensive power (Ps)
407
System comprehensive torque (N·m)
681
Number of drive motors
Dual motor
Motor layout
Front rear
Battery type
Lithium iron phosphate battery
Battery brand
Ferdy
Battery cooling method
Directly cold
WLTC pure electric cruising range (km)
140
CLTC pure electric cruising range (km)
185
NEDC Combined Range (km)
960
Battery energy (kWh)
40
Electricity consumption per 100 kilometers (kWh/100km)
23.3
Battery pack warranty
-
Fast charging function
support
Fast charging power (kW)
80
Fast charging time (hours)
-
Slow charging time (hours)
-
Fast charging capacity (%)
-
gearbox
Number of gears
Continuously variable speed
Gearbox type
Electronic continuously variable transmission (E-CVT)
abbreviation
E-CVT continuously variable transmission
chassis steering
Drive mode
Front four-wheel drive
four-wheel drive
Electric four-wheel drive
Center differential structure
-
Front suspension type
MacPherson independent suspension
rear suspension type
Multi-link independent suspension
Assist type
electric assist
Body structure
Load-bearing
wheel brake
Front brake type
ventilated disc
rear brake type
ventilated disc
Parking brake type
Electronic parking
Front tire specifications
235/60 R18
Rear tire specifications
235/60 R18
Spare tire specifications
None
