Basic parameters
Model name
Golf·Pure Electric 2020 Chi
FAW Audi
FAW-Volkswagen
Compact SUV
compact car
Gasoline
pure electric
Maximum power (kW)
2019.10
NEDC pure electric cruising range (km)
270
Fast charging time (hours)
0.63
Slow charging time (hours)
5
Fast charging percentage
80
Maximum power(kW)
100
Maximum torque (N·m)
290
Motor(Ps)
136
Length*width*height (mm)
4259*1799*1479
body structure
5-door, 5-seater hatchback
Maximum speed (km/h)
150
Official 0-100km/h acceleration (s)
-
Vehicle warranty
Four years or 120,000 kilometers
Body
length (mm)
4259
width (mm)
1799
height (mm)
1479
wheelbase (mm)
2631
front wheelbase (mm)
-
rear wheelbase (mm)
-
body structure
Hatchback
number of doors (units)
5
Number of seats (seats)
5
Trunk volume (L)
380
Curb weight (kg)
1580
electric motor
Motor type
Permanent magnet/synchronization
Total motor power (kW)
100
Total torque of motor (N·m)
290
Maximum power of front electric motor (kW)
100
Maximum torque of front electric motor (N·m)
290
Number of drive motors
single motor
Motor layout
prefix
Battery type
Ternary lithium battery
NEDC pure electric cruising range (km)
270
Battery energy (kWh)
40
Electricity consumption per 100 kilometers (kWh/100km)
13.6
Battery pack warranty
Eight years or 120,000 kilometers
Fast charging time (hours)
0.63
Slow charging time (hours)
5
Fast charging capacity (%)
80
gearbox
Number of gears
1
Gearbox type
fixed ratio gearbox
abbreviation
Electric vehicle single speed gearbox
chassis steering
Drive mode
Front wheel drive
Front suspension type
MacPherson independent suspension
rear suspension type
Multi-link independent suspension
Assist type
electric assist
Body structure
Load-bearing
wheel brake
Front brake type
ventilated disc
rear brake type
disc type
Parking brake type
Electronic parking
Front tire specifications
205/55 R16
Rear tire specifications
205/55 R16
Spare tire specifications
Not full size
