Basic parameters
Model name
NIO ET5T 2024 model 100kWh Touring
FAW Audi
NIO
Compact SUV
mid-size car
Gasoline
pure electric
Maximum power (kW)
2024.02
CLTC pure electric cruising range (km)
680
Fast charging time (hours)
0.6
Slow charging time (hours)
-
Fast charging percentage
80
Maximum power(kW)
-
Maximum torque (N·m)
-
Motor(Ps)
490
Length*width*height (mm)
4790*1960*1499
body structure
5-door 5-seat Wagon
Maximum speed (km/h)
200
Official 0-100km/h acceleration (s)
4
Vehicle warranty
Three years or 120,000 kilometers
First owner warranty policy
Six years or 150,000 kilometers
Body
length (mm)
4790
width (mm)
1960
height (mm)
1499
wheelbase (mm)
2888
front wheelbase (mm)
1685
rear wheelbase (mm)
1685
approach angle (°)
13
departure angle (°)
14
body structure
Wagon
door opening method
swing door
number of doors (units)
5
Number of seats (seats)
5
Trunk volume (L)
450-1300
Drag coefficient (Cd)
0.25
Curb weight (kg)
2245
Total mass of quasi-trailer (kg)
1400
Maximum full load mass (kg)
2730
electric motor
Motor type
Front induction/asynchronous rear permanent magnet/synchronization
Total motor power (kW)
360
Total motor power (Ps)
-
Total torque of motor (N·m)
700
Maximum power of front electric motor (kW)
150
Maximum torque of front electric motor (N·m)
280
Maximum power of rear electric motor (kW)
210
Maximum torque of rear electric motor (N·m)
420
Number of drive motors
Dual motor
Motor layout
Front rear
Battery type
Ternary lithium battery
Battery brand
Ningde Era (Jiangsu Era)
Battery cooling method
liquid cooling
Exchange battery
support
CLTC pure electric cruising range (km)
680
Battery energy (kWh)
100
Battery energy density (Wh/kg)
185.44
Electricity consumption per 100 kilometers (kWh/100km)
-
Battery pack warranty
Ten years of unlimited mileage for the first owner (the liability exemption clause shall be subject to the official)
Fast charging function
support
Fast charging power (kW)
180
Fast charging time (hours)
0.6
Slow charging time (hours)
-
Fast charging capacity (%)
80
gearbox
Number of gears
1
Gearbox type
fixed ratio gearbox
abbreviation
Electric vehicle single speed gearbox
chassis steering
Drive mode
Dual motor four-wheel drive
four-wheel drive
Electric four-wheel drive
Center differential structure
-
Front suspension type
Five-link independent suspension
rear suspension type
Five-link independent suspension
Assist type
electric assist
Body structure
Load-bearing
wheel brake
Front brake type
ventilated disc
rear brake type
ventilated disc
Parking brake type
Electronic parking
Front tire specifications
245/45 R19
Rear tire specifications
245/45 R19
Spare tire specifications
-
