Basic parameters
Model name
Audi Q5 e-tron 2023 model 40 e-tron star type brocade suit
FAW Audi
SAIC Audi
Compact SUV
Medium and large SUV
Gasoline
pure electric
Maximum power (kW)
2023.03
CLTC pure electric cruising range (km)
560
Fast charging time (hours)
-
Slow charging time (hours)
-
Fast charging percentage
-
Maximum power(kW)
-
Maximum torque (N·m)
-
Motor(Ps)
204
Length*width*height (mm)
4876*1860*1675
body structure
5-door, 7-seater SUV
Maximum speed (km/h)
160
Official 0-100km/h acceleration (s)
9.3
Electric energy equivalent fuel consumption (L/100km)
1.8
Vehicle warranty
Three years or 100,000 kilometers
First owner warranty policy
-
Body
length (mm)
4876
width (mm)
1860
height (mm)
1675
wheelbase (mm)
2965
front wheelbase (mm)
1587
rear wheelbase (mm)
1563
approach angle (°)
17
departure angle (°)
20
body structure
SUV
door opening method
swing door
number of doors (units)
5
Number of seats (seats)
7
Trunk volume (L)
1776
Curb weight (kg)
2325
Maximum full load mass (kg)
2885
electric motor
Motor type
Permanent magnet/synchronization
Total motor power (kW)
150
Total motor power (Ps)
-
Total torque of motor (N·m)
310
Maximum power of rear electric motor (kW)
150
Maximum torque of rear electric motor (N·m)
310
Number of drive motors
single motor
Motor layout
rear
Battery type
Ternary lithium battery
Battery brand
SAIC Volkswagen
Battery cooling method
liquid cooling
Exchange battery
Not supported
CLTC pure electric cruising range (km)
560
Battery energy (kWh)
83.4
Battery energy density (Wh/kg)
175
Electricity consumption per 100 kilometers (kWh/100km)
15.9
Battery pack warranty
Eight years or 160,000 kilometers
Fast charging function
support
Fast charging time (hours)
-
Slow charging time (hours)
-
Fast charging capacity (%)
-
gearbox
Number of gears
1
Gearbox type
fixed ratio gearbox
abbreviation
Electric vehicle single speed gearbox
chassis steering
Drive mode
rear wheel drive
four-wheel drive
-
Center differential structure
-
Front suspension type
MacPherson independent suspension
rear suspension type
Multi-link independent suspension
Assist type
electric assist
Body structure
Load-bearing
wheel brake
Front brake type
ventilated disc
rear brake type
Drum type
Parking brake type
Electronic parking
Front tire specifications
235/50 R20
Rear tire specifications
265/45 R20
Spare tire specifications
None
