Basic parameters
Model name
Dark Blue SL03 2024 135Plus Honor Edition
FAW Audi
dark blue car
Compact SUV
mid-size car
Gasoline
Extended range
National VI
Time to market
Maximum power (kW)
2024.02
WLTC pure electric cruising range (km)
100
CLTC pure electric cruising range (km)
135
Fast charging time (hours)
0.5
Slow charging time (hours)
-
Fast charging percentage
30-80
Maximum power(kW)
175
Maximum torque (N·m)
-
Engine
1.5L 95 HP L4
Motor(Ps)
238
gearbox
Electric vehicle single speed gearbox
Length*width*height (mm)
4820*1890*1480
body structure
5-door, 5-seater hatchback
Maximum speed (km/h)
170
Official 0-100km/h acceleration (s)
7.2
Minimum state of charge fuel consumption (L/100km)
4.4
Electric energy equivalent fuel consumption (L/100km)
1.39
Vehicle warranty
Three years or 120,000 kilometers
First owner warranty policy
-
Body
length (mm)
4820
width (mm)
1890
height (mm)
1480
wheelbase (mm)
2900
front wheelbase (mm)
1620
rear wheelbase (mm)
1630
approach angle (°)
15
departure angle (°)
20
body structure
hatchback
door opening method
swing door
number of doors (units)
5
Number of seats (seats)
5
Fuel tank volume (L)
45
Trunk volume (L)
473
Drag coefficient (Cd)
0.23
Curb weight (kg)
1780
Maximum full load mass (kg)
2175
Engine
Engine model
JL473QJ
Displacement (mL)
1480
Displacement(L)
1.5
Intake form
naturally aspirated
Engine layout
horizontal
Cylinder arrangement
L
Number of cylinders (number)
4
Number of valves per cylinder (number)
4
Valve train
DOHC
Maximum horsepower (Ps)
95
Maximum power(kW)
70
Maximum power speed (rpm)
-
Maximum torque (N·m)
-
Maximum torque speed (rpm)
-
Maximum net power (kW)
66
fuel form
Extended range
fuel grade
No. 92
Fuel supply method
Multi-point EFI
Cylinder head material
Aluminum alloy
Cylinder material
Aluminum alloy
National VI
Time to market
electric motor
Motor type
Permanent magnet/synchronization
Total motor power (kW)
175
Total motor power (Ps)
-
Total torque of motor (N·m)
320
Maximum power of rear electric motor (kW)
175
Maximum torque of rear electric motor (N·m)
320
Number of drive motors
single motor
Motor layout
rear
Battery type
Lithium iron phosphate battery
Battery brand
China New Airlines
Battery cooling method
liquid cooling
WLTC pure electric cruising range (km)
100
CLTC pure electric cruising range (km)
135
Battery energy (kWh)
18.99
Electricity consumption per 100 kilometers (kWh/100km)
13.1
Battery pack warranty
-
Fast charging function
support
Fast charging time (hours)
0.5
Slow charging time (hours)
-
Fast charging capacity (%)
30-80
gearbox
Number of gears
1
Gearbox type
fixed ratio gearbox
abbreviation
Electric vehicle single speed gearbox
chassis steering
Drive mode
rear wheel drive
four-wheel drive
-
Center differential structure
-
Front suspension type
MacPherson independent suspension
rear suspension type
Multi-link independent suspension
Assist type
electric assist
Body structure
Load-bearing
wheel brake
Front brake type
ventilated disc
rear brake type
disc type
Parking brake type
Electronic parking
Front tire specifications
245/45 R19
Rear tire specifications
245/45 R19
Spare tire specifications
None
