Basic parameters
Model name
Tiggo 8 PLUS New Energy 2022 PHEV 1.5T Style e
FAW Audi
Chery Automobile
Compact SUV
Medium SUV
Gasoline
plug-in hybrid
National VI
Time to market
Maximum power (kW)
2022.01
NEDC pure electric cruising range (km)
100
Fast charging time (hours)
-
Slow charging time (hours)
-
Fast charging percentage
-
Maximum power(kW)
240
Maximum torque (N·m)
565
Engine
1.5T 156 HP L4
Motor(Ps)
-
gearbox
3-speed DHT
Length*width*height (mm)
4722*1860*1747
body structure
5-door, 5-seater SUV
Maximum speed (km/h)
180
Official 0-100km/h acceleration (s)
7
NEDC comprehensive fuel consumption (L/100km)
1
Minimum state of charge fuel consumption (L/100km)
5
Electric energy equivalent fuel consumption (L/100km)
1.7
Vehicle warranty
Six years or 150,000 kilometers
First owner warranty policy
No limit on years/unlimited mileage (the liability exemption clause shall be subject to the official)
Body
length (mm)
4722
width (mm)
1860
height (mm)
1747
wheelbase (mm)
2710
front wheelbase (mm)
1582
rear wheelbase (mm)
1604
approach angle (°)
19
departure angle (°)
20
body structure
SUV
door opening method
swing door
number of doors (units)
5
Number of seats (seats)
5
Fuel tank volume (L)
-
Trunk volume (L)
889-1930
Curb weight (kg)
1740
Maximum full load mass (kg)
2323
Engine
Engine model
SQRE4T15C
Displacement (mL)
1498
Displacement(L)
1.5
Intake form
turbocharging
Engine layout
horizontal
Cylinder arrangement
L
Number of cylinders (number)
4
Number of valves per cylinder (number)
4
Valve train
DOHC
Maximum horsepower (Ps)
156
Maximum power(kW)
115
Maximum power speed (rpm)
5500
Maximum torque (N·m)
230
Maximum torque speed (rpm)
1750-4000
Maximum net power (kW)
108
fuel form
plug-in hybrid
fuel grade
-
Fuel supply method
Multi-point EFI
Cylinder head material
Aluminum alloy
Cylinder material
cast iron
National VI
Time to market
electric motor
Motor type
Permanent magnet/synchronization
Total motor power (kW)
-
Total motor power (Ps)
-
Total torque of motor (N·m)
-
System comprehensive power (kW)
240
System comprehensive power (Ps)
326
System comprehensive torque (N·m)
565
Number of drive motors
Dual motor
Motor layout
prefix
Battery type
Ternary lithium battery
Battery brand
Guoxuan Hi-Tech
Battery cooling method
liquid cooling
NEDC pure electric cruising range (km)
100
Battery energy (kWh)
19.27
Electricity consumption per 100 kilometers (kWh/100km)
15
Battery pack warranty
There is no limit on the number of years/mileage for the first owner of the car (the liability exemption clause shall be subject to the official)
Fast charging function
-
Fast charging time (hours)
-
Slow charging time (hours)
-
Fast charging capacity (%)
-
gearbox
Number of gears
3
Gearbox type
Dedicated Hybrid Transmission (DHT)
abbreviation
3-speed DHT
chassis steering
Drive mode
Front wheel drive
four-wheel drive
-
Center differential structure
-
Front suspension type
MacPherson independent suspension
rear suspension type
Multi-link independent suspension
Assist type
electric assist
Body structure
Load-bearing
wheel brake
Front brake type
ventilated disc
rear brake type
disc type
Parking brake type
Electronic parking
Front tire specifications
235/55 R18
Rear tire specifications
235/55 R18
Spare tire specifications
None
